Light Gauge Panel Systems - Roofs
CSI Light Gauge Panel Systems are ideal for roofing applications. Delivering exceptional organic architectural beauty for wall and soffit applications — especially when fabricated from natural metals such as copper, stainless steel, zinc, or titanium. From 0.5mm to 1mm (26ga - 18gauge).
These materials showcase subtle oil-canning that enhances their natural character, reflecting light and shadow dynamically throughout the day as the metal expands and contracts. The result is a living, evolving surface that celebrates the authenticity of natural metals.
ON THIS PAGE
Reveal Roof Panel
Reveal Roof Panel
New Paragraph
- Part ID: RRP
- Concealed fastened Panel System
- Install from the bottom upwards
- Applies over solid substructure
- Panels can be installed horizontal, vertical or diagonal and are interchangeable for accent effect
Panels are available in various sizes and shapes
- Panel Width: 6” to 54”
- Panel Length: varies
- Panel Reveal: 1/4” to 1”
Related Projects
Nature's Symphony
Sands of Time
Beyond Boundaries
Interlocking/Flat Lock Tile
This is a paragraph. Writing in paragraphs lets visitors find what they are looking for quickly and easily. Make sure the title suits the content of this text.
Interlocking/Flat Lock Tile
- Part ID: FLP
- Concealed fastened Panel System
- Install from the bottom upwards
- Applies over solid substructure
- Panels can be installed horizontal, vertical or diagonal and are interchangeable for accent effect
Panels are available in various sizes and shapes
- Convex and concave tiles
- Diamond-, Square-, and Rectangular Tiles
Available in different geometrical forms, e.g.
trapezoidal or honeycomb design - Panel Width: varies
- Panel Length: varies
- Material: Copper, Stainless Steel and Zinc
Related Projects
Nature's Symphony
Sands of Time
Beyond Boundaries
Double Lock Standing Seam Panel 1″ & 1.5″
Double Lock Standing Seam Panel 1″ & 1.5″
This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.
- Concealed fastened Panel System
- Panel Coverage: 7.5" to 30"
- Panel Length: delivery available up to 52'
- Panel Rib Height: 1" or 1.5"
- UL, ASTM and DADE Test Ratings
- Curved Panels are available
Architect Resources
CSI-LG-DLSS Double Lock Standing Seam Roofing System
Architectural specification document for project design and bidding.
Angled Seam Panel 1″ & 1.5″
Angled Seam Panel 1″ & 1.5″
This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.
- Concealed fastened Panel System
- Panel Coverage: 7.5" to 30"
- Panel Length: delivery available up to 52'
- Panel Rib Height: 1" or 1.5"
- UL, ASTM and DADE Test Ratings
- Curved Panels are available
Related Projects
Nature's Symphony
Sands of Time
Beyond Boundaries
Snap Lock Roof Panel 1" & 1.5"
Snap Lock Roof Panel 1" & 1.5"
This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.
- Concealed fastened Panel System
- Panel Coverage: 7.5" to 30"
- Panel Length: delivery available up to 52'
- Panel Rib Height: 1" or 1.5"
- UL, ASTM and DADE Test Ratings
Related Projects
Nature's Symphony
Sands of Time
Beyond Boundaries
Batten Snap Panel
Batten Snap Panel
This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.
- Concealed fastened Panel System
- Panel Coverage: 7.5" to 30"
- Panel Length: delivery available up to 52'
- Panel Rib Height: 1"
- UL and ASTM Test Ratings
- Curved Panels are available
Related Projects
Nature's Symphony
Sands of Time
Beyond Boundaries
Stepped Roof Panel
Stepped Roof Panel
This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.
- Part ID: SRP
- Concealed fastened Panel System
- Applies over solid substructure
- Panels to be installed horizontal
- Minimum Roof Slope: 3:12
- Panel Coverage: 4” to 24”
- Panel Length: up to 25'’
- Panel Rib Height: 0.5” to 1.5”
- Minimum Curving Radius: not available
- Engineered calculations for wind uplift available
Related Projects
Nature's Symphony
Sands of Time
Beyond Boundaries
Nail Strip Panel 1" & 1.5"
Nail Strip Panel 1" & 1.5"
This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more. To set up site-wide paragraph and title styles, go to Site Theme.
- Part ID: NSP1 or 1.5
- Concealed fastened and snap together Panel System
- Applies over solid substructure
- Panels can be installed horizontal or vertical and are interchangeable for accent effect
- Tapered Panels are available
- Minimum Roof Slope: 3:12
- Panel Coverage: 7.5” to 30”
- Panel Length: delivery available up to 52’
- Panel Rib Height: 1” or 1.5”
- Minimum Curving Radius: not available
Related Projects
Nature's Symphony
Sands of Time
Beyond Boundaries
Available Finishes for Light Gauge Panel Systems
